All wedges are equipped with a ring to keep the wedge attached to the tendon during elongation and/or tensioning operations.
The anchor wedges are manufactured from case hardened steel especially produced for NOOR.
Accurate, automated production plus stringent testing guarantee the highest quality.
Each individual wedge segment is
examined for exact tooth shape by computer cameras.
Anchor barrels are manufactured from high-tensile crack-tested basic material in a special process, and are only stamped and released for dispatch after final ultrasonic testing.
In this way, we ensure the highest industrial safety and long service life of the anchor components.
NOOR bonded flat slab S5 anchors use 4 No. 15.24mm seven-wire prestressing strands or 5 No. 12.7mm seven-wire prestressing strand and the maximum characteristic tensile strength of 2000 MPa
NOOR bonded flat slab S3 anchors use 2 No. 15.24mm seven-wire prestressing strands or 3 No. 12.7mm seven-wire prestressing strand and the maximum characteristic tensile strength of 2000 MPa
NOOR Galvanized Spiral Metal Duct or High Density Polyethylene Duct meets all physical and structural recommendations for post tensioning duct as laid down by the Post Tensioning Institute (of the United States). The Duct is available in 2”, 3”, and 4” diameter with couplings and reducer couplings for all sizes.
Used to improve installation of PC
Strand into Corrugated Ducts
NOOR-G is an inorganic product in powder form to be used in addition to the other components of concrete for producing shrinkage compensating and high strength concrete. It is a special clinker, burnt at high temperature, rich in free lime and whose minor compounds are calcium silicates, aluminates, Ferro-aluminates and suphates. The use of super plasticizers is particularly recommended when using NOOR - G as they significantly reduce the water content and thus the potential shrinkage of the concrete to be compensated. It can be used in post tension cable duct grouting and crack repairs and more.
Compressive Strength (ASTM C-942)* (70° F Dry Environment) 0.4 w/c Ratio
3 days 3,000 psi (20.0 MPa)
7 days 5,000 psi (33.3 MPa)
28 days 7,000 psi (46.7 MPa)
Click here to download Technical Data Sheet (TDS) for NOOR-G
Click here to download Material Safty Data Sheet (MSDS) for NOOR-G
